Caulks Creek
Contractor:
J & J Boring, Inc.
41 Cardinal Hill Road
Winfield, MO 63389Project:
Caulks Creek Pump Station B Force Main
Our crew has been hard at work completing
two 48” Micro-tunnel drives totaling 760 L.F.
in Chesterfield, Missouri. Both drives originated from
a single 40’ diameter shaft, 42’ deep and 18+ feet
below the ground water elevation. Each tunnel holed
out into a 12’ diameter shaft of the same depth and
each was within 1” of line and grade!
Great Job Guys!!Owner:
Metropolitan St. Louis Sewer District -
Harlem – Baden Relief Phase IV
Contractor:
Bates Utility Co. Inc.
841 Westwood Industrial Park Drive
Weldon Springs, MO 63304Project:
Harlem – Baden Relief Phase IV
428' long tunnel through mixed ground conditions
using an Akkerman EX960B excavator shield
skinned to 115" O.D.
Direct jacked 110" Hobas pipe which is one of the
largest pipe that Hobas manufactures.Owner:
Metropolitan St. Louis Sewer District -
Wolf River at McLean Siphon Repair
Contractor:
Magnolia Underground Construction, Inc.
7435 Byhalia Road
Olive Branch, MS 38654Project:
Wolf River at McLean Siphon Repair
(Project 2) (SW02120)
Memphis, Tennessee
1,140 LF under Wolf River
(3 Bores @ 380 LF each barrel siphon)
Launched from a single 20 foot shaft
Akkerman SL44C Microtunnel Boring Machine (MTBM)
Flowtite Fiberglass Reinforced PipeOwner:
City of Memphis, TN -
MSD - FF-15 (GBM)
Contractor:
J & J Boring, Inc.
41 Cardinal Hill Road
Winfield, MO 63389Project:
240' x 30" Slipline Three different methods used in one pit.
FF-15 McKelvey/R.R. to Adie Sanitary Relief Phase III
Letting No. 10489-015.1
4,400' x 8" - 42"Owner:
Metropolitan St. Louis Sewer District -
MSD
The Metropolitan St. Louis Sewer District (MSD)
Infrastructure Repair Project 087P Caulks Creek Sewer Line “A” (P-750) Phase IV Section B in Chesterfield, MO
General Contractor:
Gershenson Construction Co.Subcontractor:
J & J Boring,Inc.Completed in February 2010
-
Memphis, TN Project
Completed March 2017
-
MSD - UR-10 Mendell
Contractor:
J.H. Berra Construction Co., Inc.
5091 New Baumgartner Road
St. Louis, MO 63129Project:
101' x 36" - Pipe In Tunnel 18" 416' x 36" - Pipe In Tunnel 15"
UR-10 Mendell and Wolter Sanitary Relief
(SKME-595)
Letting No. 10027-015.1
582' x 54" - Pipe In Tunnel 30"Owner:
Metropolitan St. Louis Sewer District -
MSD - DC-02 & DC-03 Sanitary Relief
Contractor:
J.H. Berra Construction Co., Inc.
5091 New Baumgartner Road
St. Louis, MO 63129Project:
91' - Pipe In Tunnel 54"
DC-02 & DC-03 Sanitary Relief
(Brentwood Blvd to Conway Rd) Phase 1
Letting No. 10021-015.1
531' - Pipe In Tunnel 72"Owner:
Metropolitan St. Louis Sewer District -
MSD - Gravois Trunk
Contractor:
Tarlton Corporation
5500 West Park Avenue
St. Louis, MO 63110Project:
Gravois Trunk (Whitecliff to RDP)
Sanitary Relief Phase I (Project #90032)
279’ of liner plate tunnel in rock for 72” RCP
405’ of liner plate tunnel in rock for 90” RCPOwner:
Metropolitan St. Louis Sewer District -
MSD - FF-15 R.R. to Adie
Contractor:
J & J Boring, Inc.
41 Cardinal Hill Road
Winfield, MO 63389Project:
240' x 30" Slipline Three different methods used in one pit.
FF-15 McKelvey/R.R. to Adie Sanitary Relief Phase III
Letting No. 10489-015.1
4,400' x 8" - 42"Owner:
Metropolitan St. Louis Sewer District -
MSD - Caulks Creek Infrastructure Repair
Contractor:
Gershenson Construction Co., Inc.
2 Truitt Drive
Eureka, MO 63025Project:
Infrastructure Repair #087P Caulks Creek “A” (P-750) Phase IV – Section B
Contract Letting No. 93077C1
434’ x 48” and 600’ x 48” installed using Microtunnel Machine
Conditions ranged from saturated soft silt to solid limestoneOwner:
Metropolitan St. Louis Sewer District
